Continuous-base cable routing
Solid Bottom Cable Tray
A formed tray with a continuous base for cable routes that require full-bottom support. Specify the cover, fittings and supports separately where needed.
Define the complete route in your drawing.
Solid bottom tray is distinguished by its unperforated, continuous base. It is not the same as an enclosed cable trunking system with a removable cover. The selected dimensions, cable load, span, environment, material and finish need project review.
- Tray width, side height, thickness and section length
- Bends, tees, reducers, covers and connection details
- Support arrangement and installation environment
- Base material and surface finish specified separately
System selection
Confirm the base and enclosure required.
If your route needs ventilation, compare perforated cable tray. If it needs a removable enclosed cover, compare cable trunking. Final selection follows the project specification.
